19. Display Unit (DU)
Rev.1.00 Jan. 10, 2008 Page 937 of 1658
REJ09B0261-0100
19.4.5 Input Display Data Format
The following format is used for input color data used in display.
• 8 bit/pixel
A color palette index is used. The color palette is used to convert and display image data into
RGB data with 6 bits for each RGB color (RGB666).
The arrangement of data in memory is as follows.
A+3 A+2 A+1 A A A+1 A+2 A+3
31 23 15 7 0 31 23 15 7 0
Address A Index 3 Index 2 Index 1 Index 0 Address A Index 0 Index 1 Index 2 Index 3
Address A+4 Index 7 Index 6 Index 5 Index 4 Address A+4 Index 4 Index 5 Index 6 Index 7
Address A+8 Index 11 Index 10 Index 9 Index 8 Address A+8 Index 8 Index 9 Index 10 Index 11
Little endian Big endian
• 16 bit/pixel: RGB
The RGB levels are represented using 5 bits for R, 6 bits for G, and 5 bits for B (RGB565).
D15-D0 15 11 10 5 4 0
R G B
The arrangement of data in memory is as follows.
A+2 A A A+2
31 15 0 31 15 0
Address A RGB565 - 1 RGB565 - 0 Address A RGB565 - 0 RGB565 - 1
Address A+4 RGB565 - 3 RGB565 - 2 Address A+4 RGB565 - 2 RGB565 - 3
Address A+8 RGB565 - 5 RGB565 - 4 Address A+8 RGB565 - 4 RGB565 - 5
Little endian Big endian
