31. Register List
Rev.1.00 Jan. 10, 2008 Page 1538 of 1658
REJ09B0261-0100
Module
Name Name Abbrev.
Power-on
Reset by
PRESET Pin/
WDT/H-UDI
Manual Reset
by
WDT/Multiple
Exception
Sleep/
Deep Sleep by
SLEEP
Instruction
PCIC PCI power management interrupt mask
register
PCIPINTM H'0000 0000 Retained Retained
PCI memory bank register 0 PCIMBR0 H'0000 0000 Retained Retained
PCI memory bank mask register 0 PCIMBMR0 H'0000 0000 Retained Retained
PCI memory bank register 1 PCIMBR1 H'0000 0000 Retained Retained
PCI memory bank mask register 1 PCIMBMR1 H'0000 0000 Retained Retained
PCI memory bank register 2 PCIMBR2 H'0000 0000 Retained Retained
PCI memory bank mask register 2 PCIMBMR2 H'0000 0000 Retained Retained
PCI I/O bank register PCIIOBR H'0000 0000 Retained Retained
PCI I/O bank master register PCIIOBMR H'0000 0000 Retained Retained
PCI cache snoop control register 0 PCICSCR0 H'0000 0000 Retained Retained
PCI cache snoop control register 1 PCICSCR1 H'0000 0000 Retained Retained
PCI cache snoop address register 0 PCICSAR0 H'0000 0000 Retained Retained
PCI cache snoop address register 1 PCICSAR1 H'0000 0000 Retained Retained
PCI PIO data register PCIPDR H'xxxx xxxx Retained Retained
Notes: 1. Initial values of ICR0.NMIL and NMIFCR.NMIL depend on the level input to the NMI pin.
2. Initial values depend on the settings of external pin MODE8.
