6. Floating-Point Unit (FPU)
Rev.1.00 Jan. 10, 2008 Page 136 of 1658
REJ09B0261-0100
Table 6.3 Bit Allocation for FPU Exception Handling
Field Name
FPU
Error (E) Invalid
Operation (V) Division
by Zero (Z) Overflow
(O) Underflo
w (U) Inexact
(I)
Cause FPU exception
cause field
Bit 17 Bit 16 Bit 15 Bit 14 Bit 13 Bit 12
Enable FPU exception
enable field
None Bit 11 Bit 10 Bit 9 Bit 8 Bit 7
Flag FPU exception
flag field
None Bit 6 Bit 5 Bit 4 Bit 3 Bit 2
6.3.3 Floating-Point Communication Register (FPUL)
Information is transferred between the FPU and CPU via FPUL. FPUL is a 32-bit system register
that is accessed from the CPU side by means of LDS and STS instructions. For example, to
convert the integer stored in general register R1 to a single-precision floating-point number, the
processing flow is as follows:
R1
→ (LDS instruction) → FPUL → (single-precision FLOAT instruction) → FR1
