31. Register List
Rev.1.00 Jan. 10, 2008 Page 1556 of 1658
REJ09B0261-0100
Module
Name Name Abbrev.
Power-on
Reset by
PRESET Pin/
WDT/H-UDI
Manual Reset
by
WDT/Multiple
Exception
Sleep/
Deep Sleep by
SLEEP
Instruction
Module
Standby
MMCIF Response register 7 RSPR7 H'00 H'00 Retained Retained
Response register 8 RSPR8 H'00 H'00 Retained Retained
Response register 9 RSPR9 H'00 H'00 Retained Retained
Response register 10 RSPR10 H'00 H'00 Retained Retained
Response register 11 RSPR11 H'00 H'00 Retained Retained
Response register 12 RSPR12 H'00 H'00 Retained Retained
Response register 13 RSPR13 H'00 H'00 Retained Retained
Response register 14 RSPR14 H'00 H'00 Retained Retained
Response register 15 RSPR15 H'00 H'00 Retained Retained
Response register 16 RSPR16 H'00 H'00 Retained Retained
CRC status register RSPRD H'00 H'00 Retained Retained
Data timeout register DTOUTR H'FFFF H'FFFF Retained Retained
Data register DR H'xxxx H'xxxx Retained Retained
FIFO pointer clear register FIFOCLR H'00 H'00 Retained Retained
DMA control register DMACR H'00 H'00 Retained Retained
Interrupt control register 2 INTCR2 H'00 H'00 Retained Retained
Interrupt status register 2 INTSTR2 H'0x H'0x Retained Retained
HAC Control and status register 0 HACCR0 H'0000 0200 H'0000 0200 Retained Retained
Command/status address register 0 HACCSAR0 H'0000 0000 H'0000 0000 Retained Retained
Command/status data register 0 HACCSDR0 H'0000 0000 H'0000 0000 Retained Retained
PCM left channel register 0 HACPCML0 H'0000 0000 H'0000 0000 Retained Retained
PCM right channel register 0 HACPCMR0 H'0000 0000 H'0000 0000 Retained Retained
TX interrupt enable register 0 HACTIER0 H'0000 0000 H'0000 0000 Retained Retained
TX status register 0 HACTSR0 H'F000 0000 H'F000 0000 Retained Retained
RX interrupt enable register 0 HACRIER0 H'0000 0000 H'0000 0000 Retained Retained
RX status register 0 HACRSR0 H'0000 0000 H'0000 0000 Retained Retained
HAC control register 0 HACACR0 H'8400 0000 H'8400 0000 Retained Retained
Control and status register 1 HACCR1 H'0000 0200 H'0000 0200 Retained Retained
Command/status address register 1 HACCSAR1 H'0000 0000 H'0000 0000 Retained Retained
