19. Display Unit (DU)
Rev.1.00 Jan. 10, 2008 Page 838 of 1658
REJ09B0261-0100
Register Name Abbr.
Power-On
Reset by
PRESET
Pin/ WDT/
H-UDI
Manual
Reset by
WDT Sleep by
Sleep
Instruction
Module
Standby Deep
Sleep
Bits with
Internal Update
Function
Plane 5 wrap-
around start
position register P5WASPR Undefined Retained Retained Retained Retained All bits
Plane 5 wrap-
around memory
width register P5WAMWR Undefined Retained Retained Retained Retained All bits
Plane 5 blinking
period register P5BTR H'00000101 Retained Retained Retained Retained All bits
Plane 5
transparent color 1
register P5TC1R Undefined Retained Retained Retained Retained All bits
Plane 5
transparent color 2
register P5TC2R Undefined Retained Retained Retained Retained All bits
Plane 5 memory
length register P5MLR H'00000000 Retained Retained Retained Retained All bits
Plane 6 mode
register P6MR H'00000000 Retained Retained Retained Retained All bits
Plane 6 memory
width register P6MWR Undefined Retained Retained Retained Retained All bits
Plane 6 blend ratio
register P6ALPHAR Undefined Retained Retained Retained Retained All bits
Plane 6 display
size X register P6DSXR Undefined Retained Retained Retained Retained All bits
Plane 6 display
size Y register P6DSYR Undefined Retained Retained Retained Retained All bits
Plane 6 display
position X register P6DPXR Undefined Retained Retained Retained Retained All bits
Plane 6 display
position Y register P6DPYR Undefined Retained Retained Retained Retained All bits
Plane 6 display
area start address
0 register P6DSA0R Undefined Retained Retained Retained Retained All bits
