22. Serial I/O with FIFO (SIOF)
Rev.1.00 Jan. 10, 2008 Page 1119 of 1658
REJ09B0261-0100
Bit Bit Name
Initial
Value R/W Description
10 RCRDYE 0 R/W Receive Control Data Ready Enable
0: Disables interrupts due to receive control data ready
1: Enables interrupts due to receive control data ready
9 RFFULE 0 R/W Receive FIFO Full Enable
0: Disables interrupts due to receive FIFO full
1: Enables interrupts due to receive FIFO full
8 RDREQE 0 R/W Receive Data Transfer Request Enable
0: Disables interrupts due to receive data transfer
requests
1: Enables interrupts due to receive data transfer
requests
7, 6
⎯ All
0 R Reserved
These bits are always read as 0. The write value should
always be 0.
5 SAERRE 0 R/W Slot Assign Error Enable
0: Disables interrupts due to slot assign error
1: Enables interrupts due to slot assign error
4 FSERRE 0 R/W Frame Synchronization Error Enable
0: Disables interrupts due to frame synchronization
error
1: Enables interrupts due to frame synchronization error
3 TFOVFE 0 R/W Transmit FIFO Overflow Enable
0: Disables interrupts due to transmit FIFO overflow
1: Enables interrupts due to transmit FIFO overflow
2 TFUDFE 0 R/W Transmit FIFO Underflow Enable
0: Disables interrupts due to transmit FIFO underflow
1: Enables interrupts due to transmit FIFO underflow
1 RFUDFE 0 R/W Receive FIFO Underflow Enable
0: Disables interrupts due to receive FIFO underflow
1: Enables interrupts due to receive FIFO underflow
0 RFOVFE 0 R/W Receive FIFO Overflow Enable
0: Disables interrupts due to receive FIFO overflow
1: Enables interrupts due to receive FIFO overflow
