25. Audio Codec Interface (HAC)
Rev.1.00 Jan. 10, 2008 Page 1284 of 1658
REJ09B0261-0100
25.3.10 HAC Control Register (HACACR)
HACACR is a 32-bit read/write register used for controlling the HAC interface.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯
Bit:
1 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 Initial value:
R R/W R/W R R R/W R R/W R/W R/W R/W R R R R R
R R R R R R R R
R/W:
Bit:
Initial value:
R/W:
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R R R R R R R R
⎯ ⎯ ⎯ ⎯ ⎯ ⎯
TX12_
ATOMIC
RXDMAL
_EN
TXDMAL
_EN
RXDMAR
_EN
TXDMAR
_EN
DMA
RX16
DMA
TX16
0
Bit Bit Name
Initial
Value R/W Description
31
⎯ 1
R Reserved
This bit is always read as 1. The write value should
always be 1.
30 DMARX16 0 R/W 16-bit RX DMA Enable
0: Disables 16-bit packed RX DMA mode. Enables the
RXDMAL_EN and RXDMAR_EN settings.
1: Enables 16-bit packed RX DMA mode. Disables the
RXDMAL_EN and RXDMAR_EN settings.
29 DMATX16 0 R/W 16-bit TX DMA Enable
0: Disables 16-bit packed TX DMA mode. Enables the
TXDMAL_EN and TXDMAR_EN settings.
1: Enables 16-bit packed TX DMA mode. Disables the
TXDMAL_EN and TXDMAR_EN settings.
28, 27
⎯ All
0 R Reserved
These bits are always read as 0. The write value should
always be 0.
26 TX12_ATOMIC 1 R/W TX Slot 1 and 2 Atomic Control
0: Transmits TX data in HACCSAR and that in
HACCSDR separately. (Setting prohibited)
1: Transmits TX data in HACCSAR and that in
HACCSDR in the same frame if bit 19 in HACCSAR
is 0 (write). (HACCSAR must be written last.)
