30. User Debugging Interface (H-UDI)
Rev.1.00 Jan. 10, 2008 Page 1496 of 1658
REJ09B0261-0100
Number Pin Name Type Number Pin Name Type
435
WE7/CBE3 Input
403 D57/AD25 Output
434
WE7/CBE3 Control
402 D56/AD24 Input
433
WE7/CBE3 Output
401 D56/AD24 Control
432
WE6/CBE2 Input
400 D56/AD24 Output
431
WE6/CBE2 Control
399 D55/AD23 Input
430
WE6/CBE2 Output
398 D55/AD23 Control
429
WE5/CBE1 Input
397 D55/AD23 Output
428
WE5/CBE1 Control
396 D54/AD22 Input
427
WE5/CBE1 Output
395 D54/AD22 Control
426
WE4/CBE0 Input
394 D54/AD22 Output
425
WE4/CBE0 Control
393 D53/AD21 Input
424
WE4/CBE0 Output
392 D53/AD21 Control
423 D63/AD31 Input 391 D53/AD21 Output
422 D63/AD31 Control 390 D52/AD20 Input
421 D63/AD31 Output 389 D52/AD20 Control
420 D62/AD30 Input 388 D52/AD20 Output
419 D62/AD30 Control 387 D51/AD19 Input
418 D62/AD30 Output 386 D51/AD19 Control
417 D61/AD29 Input 385 D51/AD19 Output
416 D61/AD29 Control 384 D50/AD18 Input
415 D61/AD29 Output 383 D50/AD18 Control
414 D60/AD28 Input 382 D50/AD18 Output
413 D60/AD28 Control 381 D49/AD17/DB5 Input
412 D60/AD28 Output 380 D49/AD17/DB5 Control
411 D59/AD27 Input 379 D49/AD17/DB5 Output
410 D59/AD27 Control 378 D48/AD16/DB4 Input
409 D59/AD27 Output 377 D48/AD16/DB4 Control
408 D58/AD26 Input 376 D48/AD16/DB4 Output
407 D58/AD26 Control 375 D47/AD15/DB3 Input
406 D58/AD26 Output 374 D47/AD15/DB3 Control
405 D57/AD25 Input 373 D47/AD15/DB3 Output
404 D57/AD25 Control 372 D46/AD14/DB2 Input
