17. Power-Down Mode
Rev.1.00 Jan. 10, 2008 Page 788 of 1658
REJ09B0261-0100
Bit Bit Name
Initial
Value R/W
Description
9, 8 MSTP[9:8] All 0 R/W Module Stop Bit [9:8]
Specify that the clock supply to the module of the
corresponding bit is stopped
[9]: TMU channels 3 to 5
[8]: TMU channels 2 to 0
0: The corresponding module operates
1: The clock to the corresponding module is
stopped
7 to 4
⎯ All
0 R/W Reserved
These bits are always read as 0. The write value
should always be 0.
3, 2 MSTP[3:2] All 0 R/W Module Stop Bit [3:2]
Specify that the clock supply to the module of the
corresponding bit is stopped
[3]: SIOF, [2]: HSPI
0: The corresponding module operates
1: The clock to the corresponding module is
stopped
1, 0
⎯ All
0 R/W Reserved
These bits are always read as 0. The write value
should always be 0.
