4. Pipelining
Rev.1.00 Jan. 10, 2008 Page 71 of 1658
REJ09B0261-0100
I1 I2 I3 ID s1 s2 s3 WB
I3
I3
I3
I3
I3
I3
I3
I1 I2 ID WB
I1 I2 ID S1 S2 S3
E1s1 E2s2 E3s3
WB
I1 I2 ID WB
I1 I2 ID S1 S2 S3
E1S1 E2S2 E3S3
WB
I1 I2 ID s1 s2 s3 WB
I1 I2 ID s1 s2 s3 WB
I1 I2 ID S1 S2 S3 WB
(I1) (I2) (I3) (ID) (??1) (??2) (??3) (WB)
(4-9) STC from DBR/GBR/Rp_BANK/SSR/SPC/VBR/SGR: 1 issue cycle
(4-10) STC from SR: 1 issue cycle
(4-11) STC.L from DBR/GBR/Rp_BANK/SSR/SPC/VBR/SGR: 1 issue cycle
(4-12) STC.L from SR: 1 issue cycle
(4-13) LDS to PR: 1 issue cycle
(4-14) LDS.L to PR: 1 issue cycle
(4-15) STS from PR: 1 issue cycle
(4-16) STS.L from PR: 1 issue cycle
(4-17) BSRF, BSR, JSR delay slot instructions (PR set): 0 issue cycle
The value of PR is changed in the E3 stage of delay slot instruction.
When the STS and STS.L instructions from PR are used as delay slot instructions,
changed PR value is used. Notes:
Figure 4.2 Instruction Execution Patterns (5)
