Renesas SH7781 - Manual (Page 1661)

Appendix
Rev.1.00 Jan. 10, 2008 Page 1631 of 1658
REJ09B0261-0100
C. Pin Functions
C.1 Pin States
Table C.1 Pin States in Reset, Power-Down State, and Bus-Released State
Reset
Pin Name
(LSI level) Pin Name
(Module level) Related
Module I/O Power-
on Manual Sleep Module
Standby Bus
Release
A[25:0] A[25:0] LBSC O PZ K K ⎯ PZ/Z
D[31:24] (default) LBSC I/O Z K K ⎯ Z D[31:24]
Port F[7:0] GPIO I/O ⎯ K K ⎯ Z
D[23:16] (default) LBSC I/O Z K K ⎯ Z D[23:16]
Port G[7:0] GPIO I/O ⎯ K K ⎯ Z
D[15:0] D[15:0] LBSC I/O Z K K ⎯ Z
CS[6:0] CS[6:0] LBSC
O H(m)/
PZ(s)
* 1
K K ⎯ PZ/Z
BACK/BSREQ
(default)
LBSC I/O H* 2 K K ⎯ O
BACK/BSREQ
Port M0 GPIO I/O ⎯ K K ⎯ O
BREQ/BSACK
(default)
LBSC I/O PZ K K ⎯ I
BREQ/BSACK
Port M1 GPIO I/O ⎯ K K ⎯ I
BS BS LBSC
O H(m)/
PZ(s)
* 1
K K ⎯ PZ/Z
R/
W R/W LBSC
O H(m)/
PZ(s)
* 1
K K ⎯ PZ/Z
RD/FRAME RD/FRAME LBSC
O H(m)/
PZ(s)
* 1
K K ⎯ PZ/Z
RDY RDY LBSC
I PI K K ⎯ I
WE0/REG WE0/REG LBSC
O H(m)/
PZ(s)
* 1
K K ⎯ PZ/Z
WE1 WE1 LBSC
O H(m)/
PZ(s)
* 1
K K ⎯ PZ/Z
WE2/IORD WE2/IORD LBSC
O H(m)/
PZ(s)
* 1
K K ⎯ PZ/Z
WE3/IOWR WE3/IOWR LBSC
O H(m)/
PZ(s)
* 1
K K ⎯ PZ/Z
