3. Instruction Set
Rev.1.00 Jan. 10, 2008 Page 59 of 1658
REJ09B0261-0100
Table 3.8 Branch Instructions
Instruction Operation Instruction Code Privileged T Bit New
BF label When T = 0, disp × 2 + PC +
4 → PC
When T = 1, nop
10001011dddddddd — — —
BF/S label Delayed branch; when T = 0,
disp
× 2 + PC + 4 → PC
When T = 1, nop
10001111dddddddd — — —
BT label When T = 1, disp
× 2 + PC +
4
→ PC
When T = 0, nop
10001001dddddddd — — —
BT/S label Delayed branch; when T = 1,
disp
× 2 + PC + 4 → PC
When T = 0, nop
10001101dddddddd — — —
BRA label Delayed branch, disp
× 2 +
PC + 4
→ PC
1010dddddddddddd — — —
BRAF Rn Delayed branch, Rn + PC + 4
→
PC
0000nnnn00100011 — — —
BSR label Delayed branch, PC + 4
→ PR,
disp × 2 + PC + 4 → PC
1011dddddddddddd — — —
BSRF Rn Delayed branch, PC + 4
→ PR,
Rn + PC + 4 → PC
0000nnnn00000011 — — —
JMP @Rn Delayed branch, Rn
→ PC
0100nnnn00101011 — — —
JSR @Rn Delayed branch, PC + 4
→ PR,
Rn
→ PC
0100nnnn00001011 — — —
RTS Delayed branch, PR
→ PC
0000000000001011 — — —
Table 3.9 System Control Instructions
Instruction Operation Instruction Code Privileged T Bit New
CLRMAC 0 → MACH, MACL
0000000000101000 — — —
CLRS 0 → S
0000000001001000 — — —
CLRT 0
→ T
0000000000001000 — 0 —
ICBI @Rn Invalidates instruction cache block 0000nnnn11100011 ⎯
⎯ New
LDC Rm,SR Rm
→ SR
0100mmmm00001110 Privileged LSB —
LDC Rm,GBR Rm
→ GBR
0100mmmm00011110 — — —
LDC Rm,VBR Rm → VBR
0100mmmm00101110 Privileged — —
LDC Rm,SGR Rm → SGR
0100mmmm00111010 Privileged — —
