30. User Debugging Interface (H-UDI)
Rev.1.00 Jan. 10, 2008 Page 1497 of 1658
REJ09B0261-0100
Number Pin Name Type Number Pin Name Type
371 D46/AD14/DB2 Control 340 D36/AD4/DR4 Output
370 D46/AD14/DB2 Output 339 D35/AD3/DR3 Input
369 D45/AD13/DB1 Input 338 D35/AD3/DR3 Control
368 D45/AD13/DB1 Control 337 D35/AD3/DR3 Output
367 D45/AD13/DB1 Output 336 D34/AD2/DR2 Input
366 D44/AD12/DB0 Input 335 D34/AD2/DR2 Control
365 D44/AD12/DB0 Control 334 D34/AD2/DR2 Output
364 D44/AD12/DB0 Output 333 D33/AD1/DR1 Input
363 D43/AD11/DG5 Input 332 D33/AD1/DR1 Control
362 D43/AD11/DG5 Control 331 D33/AD1/DR1 Output
361 D43/AD11/DG5 Output 330 D32/AD0/DR0 Input
360 D42/AD10/DG4 Input 329 D32/AD0/DR0 Control
359 D42/AD10/DG4 Control 328 D32/AD0/DR0 Output
358 D42/AD10/DG4 Output 327 CLKOUTENB Input
357 D41/AD9/DG3 Input 326 CLKOUTENB Control
356 D41/AD9/DG3 Control 325 CLKOUTENB Output
355 D41/AD9/DG3 Output 324 CLKOUT Input
354 D40/AD8/DG2 Input 323 CLKOUT Control
353 D40/AD8/DG2 Control 322 CLKOUT Output
352 D40/AD8/DG2 Output 321
RDY Input
351 D39/AD7/DG1 Input 320
RDY Control
350 D39/AD7/DG1 Control 319
RDY Output
349 D39/AD7/DG1 Output 318
WE3 Input
348 D38/AD6/DG0 Input 317
WE3 Control
347 D38/AD6/DG0 Control 316
WE3 Output
346 D38/AD6/DG0 Output 315
WE2 Input
345 D37/AD5/DR5 Input 314
WE2 Control
344 D37/AD5/DR5 Control 313
WE2 Output
343 D37/AD5/DR5 Output 312
WE1 Input
342 D36/AD4/DR4 Input 311
WE1 Control
341 D36/AD4/DR4 Control 310
WE1 Output
