Renesas SH7781 User Manual
Page 494
12. DDR2-SDRAM Interface (DBSC2)
Rev.1.00 Jan. 10, 2008 Page 464 of 1658
REJ09B0261-0100
5. SDRAM pins should be connected as shown below.
Memory #3 Pins
SH7785 Pins
DQS MDQS1
DQS MDQS1
DM MDM1
DQ7 MDQ15
DQ6 MDQ14
DQ5 MDQ13
DQ4 MDQ12
DQ3 MDQ11
DQ2 MDQ10
DQ1 MDQ9
DQ0 MDQ8
6. SDRAM pins should be connected as shown below.
Memory #4 Pins
SH7785 Pins
DQS MDQS0
DQS MDQS0
DM MDM0
DQ7 MDQ7
DQ6 MDQ6
DQ5 MDQ5
DQ4 MDQ4
DQ3 MDQ3
DQ2 MDQ2
DQ1 MDQ1
DQ0 MDQ0
