24. Multimedia Card Interface (MMCIF)
Rev.1.00 Jan. 10, 2008 Page 1239 of 1658
REJ09B0261-0100
24.5 MMCIF Interrupt Sources
Table 24.7 lists the MMCIF interrupt sources. The interrupt sources are classified into four groups,
and four interrupt vectors are assigned. Each interrupt source can be individually enabled by the
enable bits in INTCR0 to INTCR2. Disabled interrupt sources do not set the flag.
Table 24.7 MMCIF Interrupt Sources
Name Interrupt source Interrupt flag
FIFO empty FEI FSTAT
FIFO full FFI
Data response DRPI
Data transfer end DTI
Command response receive end CRPI
Command transmit end CMDI
TRAN
Data busy end DBSYI
CRC error CRCERI
Data timeout error DTERI
ERR
Command timeout error CTERI
FRDY FIFO ready FRDYI
