19. Display Unit (DU)
Rev.1.00 Jan. 10, 2008 Page 829 of 1658
REJ09B0261-0100
Register Name Abbr. R/W
P4
Address Area 7
Address Size Synchronous
Clock
Color palette registers
Color palette 1 register 000 CP1_000R R/W H'FFF81000 H'1FF81000 32 Pck
⎯
Color palette 1 register 255 CP1_255R R/W H'FFF813FC H'1FF813FC 32 Pck
Color palette 2 register 000 CP2_000R R/W H'FFF82000 H'1FF82000 32 Pck
⎯
Color palette 2 register 255 CP2_255R R/W H'FFF823FC H'1FF823FC 32 Pck
Color palette 3 register 000 CP3_000R R/W H'FFF83000 H'1FF83000 32 Pck
⎯
Color palette 3 register 255 CP3_255R R/W H'FFF833FC H'1FF833FC 32 Pck
Color palette 4 register 000 CP4_000R R/W H'FFF84000 H'1FF84000 32 Pck
⎯
Color palette 4 register 255 CP4_255R R/W H'FFF843FC H'1FF843FC 32 Pck
External synchronization control register
External synchronization control
register ESCR R/W H'FFF90000 H'1FF90000 32 Pck
Output signal timing adjustment
register OTAR R/W H'FFF90004 H'1FF90004 32 Pck
