13. PCI Controller (PCIC)
Rev.1.00 Jan. 10, 2008 Page 624 of 1658
REJ09B0261-0100
(24) PCI Cache Snoop Control Register 0 (PCICSCR0)
An external PCI device can access memory of this LSI via the PCIC. When an PCI device
accesses a cacheable area, the PCIC can issue cache snoop commands to the on-chip caches. This
register can specify the function that uses PCICSAR0. For details, see section 13.4.4 (7), Cache
Coherency.
SH R/W:
PCI R/W:
SH R/W:
PCI R/W:
16 17 18 19 20 21 22 23 24 25 26 27 28 29 31 30 Bit:
Initial value:
R/W R/W R/W R/W
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
SNPMD RANGE
R/W R R R R R R R R R R R
R R R R R R R R R R R R R R R R
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
— — — — — — — — — — —
— — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — —
— — — — — — — — — — — — — — — —
0 1 2 3 4 5 6 7 8 9 10 11 12 13 15 14 Bit:
Initial value:
Bit Bit Name
Initial
Value R/W
Description
31 to 5
⎯
All 0 SH: R
PCI: —
Reserved
These bits are always read as 0. The write value
should always be 0.
4 to 2 RANGE All 0 SH: R/W
PCI: —
Address Range to be Compared
These bits specify the address range of PCICSAR0 to
be compared.
000: Compared with PCICSAR0.CADR[31:12] (4 kbytes)
001: Compared with PCICSAR0.CADR[31:16] (64 kbytes)
010: Compared with PCICSAR0.CADR[31:20] (1 Mbyte)
011: Compared with PCICSAR0.CADR[31:24] (16 Mbytes)
100: Compared with PCICSAR0.CADR[31:25] (32 Mbytes)
101: Compared with PCICSAR0.CADR[31:26] (64 Mbytes)
110: Compared with PCICSAR0.CADR[31:27] (128 Mbytes)
111: Compared with PCICSAR0.CADR[31:28] (256 Mbytes)
Valid only when PCICSCR0.SNPMD = 10 or 11.
