4. Pipelining
Rev.1.00 Jan. 10, 2008 Page 85 of 1658
REJ09B0261-0100
Functional
Category
No. Instruction
Instruction
Group
Issue Rate
Execution
Cycles Execution
Pattern
150 LDC.L @Rm+,SPC LS 1 1 4-5
151 LDC.L @Rm+,VBR LS 1 1 4-5
152 LDS Rm,MACH LS 1 1 5-1
153 LDS Rm,MACL LS 1 1 5-1
154 LDS Rm,PR LS 1 1 4-13
155 LDS.L @Rm+,MACH LS 1 1 5-2
156 LDS.L @Rm+,MACL LS 1 1 5-2
157 LDS.L @Rm+,PR LS 1 1 4-14
158 STC DBR,Rn LS 1 1 4-9
159 STC SGR,Rn LS 1 1 4-9
160 STC GBR,Rn LS 1 1 4-9
161 STC Rp_BANK,Rn LS 1 1 4-9
162 STC SR,Rn CO 1 1 4-10
163 STC SSR,Rn LS 1 1 4-9
164 STC SPC,Rn LS 1 1 4-9
165 STC VBR,Rn LS 1 1 4-9
166 STC.L DBR,@-Rn LS 1 1 4-11
167 STC.L SGR,@-Rn LS 1 1 4-11
168 STC.L GBR,@-Rn LS 1 1 4-11
169 STC.L Rp_BANK,@-Rn LS 1 1 4-11
170 STC.L SR,@-Rn CO 1 1 4-12
171 STC.L SSR,@-Rn LS 1 1 4-11
172 STC.L SPC,@-Rn LS 1 1 4-11
173 STC.L VBR,@-Rn LS 1 1 4-11
174 STS MACH,Rn LS 1 1 5-3
175 STS MACL,Rn LS 1 1 5-3
176 STS PR,Rn LS 1 1 4-15
System
control
instructions
177 STS.L MACH,@-Rn LS 1 1 5-4
178 STS.L MACL,@-Rn LS 1 1 5-4
179 STS.L PR,@-Rn LS 1 1 4-16
