29. User Break Controller (UBC)
Rev.1.00 Jan. 10, 2008 Page 1468 of 1658
REJ09B0261-0100
29.2.5 Match Data Setting Register 1 (CDR1)
CDR1 is a readable/writable 32-bit register which specifies the data value to be included in the
break conditions for channel 1.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
CD
CD
R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit :
Initial value :
R/W:
Bit :
Initial value :
R/W:
Bit Bit Name
Initial
Value R/W
Description
31 to 0 CD Undefined R/W Compare Data Value
Specifies the data value to be included in the break
conditions.
When the operand bus has been specified using the
CBR1 register, specify the SDB data value in CD[31:0].
Table 29.3 Settings for Match Data Setting Register
Bus and Size Selected
Using CBR1
CD[31:24] CD[23:16] CD[15:8] CD[7:0]
Operand bus (byte) Don't care Don't care Don't care SDB7 to SDB0
Operand bus (word) Don't care Don't care SDB15 to SDB8 SDB7 to SDB0
Operand bus (longword) SDB31 to SDB24 SDB23 to SDB16 SDB15 to SDB8 SDB7 to SDB0
Notes: 1. If the data value is included in the match conditions, be sure to specify the operand
size.
2. The OCBI instruction is handled as longword write access without the data value, and
the PREF, OCBP, and OCBWB instructions are handled as longword read access
without the data value. Therefore, do not include the data value in the match conditions
for these instructions.
3. If the quadword access is specified and the data value is included in the match
conditions, the upper and lower 32 bits of 64-bit data are each compared with the
contents of both the match data setting register and match data mask setting register.
