10. Interrupt Controller (INTC)
Rev.1.00 Jan. 10, 2008 Page 317 of 1658
REJ09B0261-0100
(3)
INT2B2: Detailed Interrupt Sources for the DMAC
Module Bit
Name
Detailed
Source
Description
DMAC
31 to 14
⎯ Reserved
These bits are read as 0
and cannot be modified.
13
DMAE1
Channels 6 to 11 DMA
address error interrupt
12
DMINT11
Channel 11 DMA transfer
end or half-end interrupt
11
DMINT10
Channel 10 DMA transfer
end or half-end interrupt
DMAC interrupt sources are
indicated. This register indicates
the DMAC interrupt sources
even if the mask setting for
DMAC is made in the interrupt
mask register.
10
DMINT9
Channel 9 DMA transfer
end or half-end interrupt
9
DMINT8
Channel 8 DMA transfer
end or half-end interrupt
8
DMINT7
Channel 7 DMA transfer
end or half-end interrupt
7
DMINT6
Channel 6 DMA transfer
end or half-end interrupt
6
DMAE0
Channels 0 to 5 DMA
address error interrupt
5
DMINT5
Channel 5 DMA transfer
end or half-end interrupt
4
DMINT4
Channel 4 DMA transfer
end or half-end interrupt
3
DMINT3
Channel 3 DMA transfer
end or half-end interrupt
2
DMINT2
Channel 2 DMA transfer
end or half-end interrupt
1
DMINT1
Channel 1 DMA transfer
end or half-end interrupt
0
DMINT0
Channel 0 DMA transfer
end or half-end interrupt
