24. Multimedia Card Interface (MMCIF)
Rev.1.00 Jan. 10, 2008 Page 1176 of 1658
REJ09B0261-0100
Register Name Abbrev.
Power-on
Reset by
PRESET
Pin/WDT/
H-UDI
Manual Reset
by WDT/
Multiple
Exception
Sleep by
SLEEP
Instruction
Module
Standby
Response register 6 RSPR6 H'00 H'00 Retained Retained
Response register 7 RSPR7 H'00 H'00 Retained Retained
Response register 8 RSPR8 H'00 H'00 Retained Retained
Response register 9 RSPR9 H'00 H'00 Retained Retained
Response register 10 RSPR10 H'00 H'00 Retained Retained
Response register 11 RSPR11 H'00 H'00 Retained Retained
Response register 12 RSPR12 H'00 H'00 Retained Retained
Response register 13 RSPR13 H'00 H'00 Retained Retained
Response register 14 RSPR14 H'00 H'00 Retained Retained
Response register 15 RSPR15 H'00 H'00 Retained Retained
Response register 16 RSPR16 H'00 H'00 Retained Retained
CRC status register RSPRD H'00 H'00 Retained Retained
Data timeout register DTOUTR H'FFFF H'FFFF Retained Retained
Data register DR H'xxxx H'xxxx Retained Retained
FIFO pointer clear register FIFOCLR H'00 H'00 Retained Retained
DMA control register DMACR H'00 H'00 Retained Retained
Interrupt control register 2 INTCR2 H'00 H'00 Retained Retained
Interrupt status register 2 INTSTR2 H'0x H'0x Retained Retained
