31. Register List
Rev.1.00 Jan. 10, 2008 Page 1531 of 1658
REJ09B0261-0100
Module
Name Name Abbreviation R/W
P4 Area
Address
Area 7
Address
Access
Size
GPIO Port H control register PHCR R/W H'FFE7 000E H'1FE7 000E 16
Port J control register PJCR R/W H'FFE7 0010 H'1FE7 0010 16
Port K control register PKCR R/W H'FFE7 0012 H'1FE7 0012 16
Port L control register PLCR R/W H'FFE7 0014 H'1FE7 0014 16
Port M control register PMCR R/W H'FFE7 0016 H'1FE7 0016 16
Port N control register PNCR R/W H'FFE7 0018 H'1FE7 0018 16
Port P control register PPCR R/W H'FFE7 001A H'1FE7 001A 16
Port Q control register PQCR R/W H'FFE7 001C H'1FE7 001C 16
Port R control register PRCR R/W H'FFE7 001E H'1FE7 001E 16
Port A data register PADR R/W H'FFE7 0020 H'1FE7 0020 8
Port B data register PBDR R/W H'FFE7 0022 H'1FE7 0022 8
Port C data register PCDR R/W H'FFE7 0024 H'1FE7 0024 8
Port D data register PDDR R/W H'FFE7 0026 H'1FE7 0026 8
Port E data register PEDR R/W H'FFE7 0028 H'1FE7 0028 8
Port F data register PFDR R/W H'FFE7 002A H'1FE7 002A 8
Port G data register PGDR R/W H'FFE7 002C H'1FE7 002C 8
Port H data register PHDR R/W H'FFE7 002E H'1FE7 002E 8
Port J data register PJDR R/W H'FFE7 0030 H'1FE7 0030 8
Port K data register PKDR R/W H'FFE7 0032 H'1FE7 0032 8
Port L data register PLDR R/W H'FFE7 0034 H'1FEA 0034 8
Port M data register PMDR R/W H'FFE7 0036 H'1FEA 0036 8
Port N data register PNDR R/W H'FFE7 0038 H'1FEA 0038 8
Port P data register PPDR R/W H'FFE7 003A H'1FEA 003A 8
Port Q data register PQDR R/W H'FFE7 003C H'1FEA 003C 8
Port R data register PRDR R/W H'FFE7 003E H'1FEA 003E 8
Port E pull-up control register PEPUPR R/W H'FFE7 0048 H'1FEA 0048 8
Port H pull-up control register PHPUPR R/W H'FFE7 004E H'1FEA 004E 8
Port J pull-up control register PJPUPR R/W H'FFE7 0050 H'1FE7 0050 8
Port K pull-up control register PKPUPR R/W H'FFE7 0052 H'1FE7 0052 8
Port L pull-up control register PLPUPR R/W H'FFE7 0054 H'1FE7 0054 8
Port M pull-up control register PMPUPR R/W H'FFE7 0056 H'1FE7 0056 8
