14. Direct Memory Access Controller (DMAC)
Rev.1.00 Jan. 10, 2008 Page 709 of 1658
REJ09B0261-0100
14.4.3 DMA Transfer Types
Tables 14.9 and 14.10 show the transfer directions that can be supported by the DMAC.
DMA transfer type supports dual address mode. A data transfer timing depends on the bus mode.
Bus modes include cycle steal mode and burst mode.
Table 14.9 DMA Transfer Directions for Auto-Request and External Request* 2
Transfer Destination
Transfer Source
LBSC
Space DBSC
Space PCIC
Space
On-Chip
Peripheral
Module*
1
L or U
Memory
LBSC Space Y Y Y Y Y
DBSC Space Y Y Y Y Y
PCIC Space Y Y Y Y Y
On-Chip Peripheral
Module*
1
Y Y Y Y Y
L or U Memory Y Y Y Y Y
Legend:
Y: Transfer is enabled.
Notes: 1. This is the access size that is permitted by a register when the transfer source or
destination is a peripheral module.
2. External requests apply to only channels 0 to 3.
