19. Display Unit (DU)
Rev.1.00 Jan. 10, 2008 Page 836 of 1658
REJ09B0261-0100
Register Name Abbr.
Power-On
Reset by
PRESET
Pin/ WDT/
H-UDI
Manual
Reset by
WDT Sleep by
Sleep
Instruction
Module
Standby Deep
Sleep
Bits with
Internal Update
Function
Plane 3
transparent color 2
register P3TC2R Undefined Retained Retained Retained Retained All bits
Plane 3 memory
length register P3MLR H'00000000 Retained Retained Retained Retained All bits
Plane 4 mode
register P4MR H'00000000 Retained Retained Retained Retained All bits
Plane 4 memory
width register P4MWR Undefined Retained Retained Retained Retained All bits
Plane 4 blend ratio
register P4ALPHAR Undefined Retained Retained Retained Retained All bits
Plane 4 display
size X register P4DSXR Undefined Retained Retained Retained Retained All bits
Plane 4 display
size Y register P4DSYR Undefined Retained Retained Retained Retained All bits
Plane 4 display
position X register P4DPXR Undefined Retained Retained Retained Retained All bits
Plane 4 display
position Y register P4DPYR Undefined Retained Retained Retained Retained All bits
Plane 4 display
area start address
0 register P4DSA0R Undefined Retained Retained Retained Retained All bits
Plane 4 display
area start address
1 register P4DSA1R Undefined Retained Retained Retained Retained All bits
Plane 4 start
position X register P4SPXR Undefined Retained Retained Retained Retained All bits
Plane 4 start
position Y register P4SPYR Undefined Retained Retained Retained Retained All bits
Plane 4 wrap-
around start
position register P4WASPR Undefined Retained Retained Retained Retained All bits
Plane 4 wrap-
around memory
width register P4WAMWR Undefined Retained Retained Retained Retained All bits
