13. PCI Controller (PCIC)
Rev.1.00 Jan. 10, 2008 Page 560 of 1658
REJ09B0261-0100
Table 13.3 Register States in Each Processing Mode
Name Abbreviation Power-On Reset Manual Reset Sleep Mode
Control register space (physical address: H'FE00 0000 to H'FE03 FFFF)
PCIC enable control register PCIECR H'0000 0000 Retained Retained
PCI configuration register space (physical address: H'FE04 0000 to H'FE04 00FF)
PCI vendor ID register PCIVID H'1912 Retained Retained
PCI device ID register PCIDID H'0007 Retained Retained
PCI command register PCICMD H'0080 Retained Retained
PCI status register PCISTATUS H'0290 Retained Retained
PCI revision ID register PCIRID H'xx Retained Retained
PCI program interface register PCIPIF H'00 Retained Retained
PCI sub class code register PCISUB H'00 Retained Retained
PCI base class code register PCIBCC H'xx Retained Retained
PCI cache line size register PCICLS H'20 Retained Retained
PCI latency timer register PCILTM H'00 Retained Retained
PCI header type register PCIHDR H'00 Retained Retained
PCI BIST register PCIBIST H'00 Retained Retained
PCI I/O base address register PCIIBAR H'0000 0001 Retained Retained
PCI Memory base address register 0 PCIMBAR0 H'0000 0000 Retained Retained
PCI Memory base address register 1 PCIMBAR1 H'0000 0000 Retained Retained
PCI subsystem vendor ID register PCISVID H'0000 Retained Retained
PCI subsystem ID register PCISID H'0000 Retained Retained
PCI capabilities pointer register PCICP H'40 Retained Retained
PCI interrupt line register PCIINTLINE H'00 Retained Retained
PCI interrupt pin register PCIINTPIN H'01 Retained Retained
PCI minimum grant register PCIMINGNT H'00 Retained Retained
PCI maximum latency register PCIMAXLAT H'00 Retained Retained
PCI capability ID register PCICID H'01 Retained Retained
PCI next item pointer register PCINIP H'00 Retained Retained
PCI power management capability register PCIPMC H'000A Retained Retained
PCI power management control/status register PCIPMCSR H'0000 Retained Retained
PCI PMCSR bridge support extension register PCIPMCSR_
BSE
H'00 Retained Retained
