13. PCI Controller (PCIC)
Rev.1.00 Jan. 10, 2008 Page 582 of 1658
REJ09B0261-0100
(22) Maximum Latency Register (PCIMAXLAT)
This register is not programmable.
0 1 2 3 4 5 6 7
0 0 0 0 0 0 0 0
MAXLAT
R R R R R R R R
Bit:
Initial value:
SH R/W:
R R R R R R R R PCI R/W:
Bit Bit Name
Initial
Value R/W
Description
7 to 0 MAXLAT H'00 SH: R
PCI: R
Maximum Latency Specification (MILAT7 to MILAT0)
These bits specify the maximum time from requesting
the bus mastership by the PCI master device to
acquiring bus (not supported).
(23) PCI Capability Identifier Register (PCICID)
0 1 2 3 4 5 6 7
1 0 0 0 0 0 0 0
CID
R R R R R R R R
Bit:
Initial value:
SH R/W:
R R R R R R R R PCI R/W:
Bit Bit Name
Initial
Value R/W
Description
7 to 0 CID H'01 SH: R
PCI: R
Extension Function ID
These bits specify the extension function ID.
H'01: Indicates that the expansion function is power
management.
