27. NAND Flash Memory Controller (FLCTL)
Rev.1.00 Jan. 10, 2008 Page 1353 of 1658
REJ09B0261-0100
27.3.7
Data Register (FLDATAR)
FLDATAR is a 32-bit readable/writable register. It stores data to be input or output used when the
CDSRC bit in FLCMDCR is cleared to 0 in command access mode.
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Bit:
Initial value:
R/W:
Bit:
Initial value:
R/W:
DT[31:24] DT[23:16]
DT[15:8] DT[7:0]
Bit Bit
Name
Initial
Value R/W Description
31 to 24 DT[31:24] H'00 R/W
Fourth
Data
Specify the 4th data to be input or output via the FD7 to
FD0 pins.
In writing: Specify write data
In reading: Store read data
23 to 16 DT[23:16] H'00 R/W
Third
Data
Specify the 3rd data to be input or output via the FD7 to
FD0 pins.
In writing: Specify write data
In reading: Store read data
15 to 8
DT[15:8]
H'00
R/W
Second Data
Specify the 2nd data to be input or output via the FD7
to FD0 pins.
In writing: Specify write data
In reading: Store read data
7 to 0
DT[7:0]
H'00
R/W
First Data
Specify the 1st data to be input or output via the FD7 to
FD0 pins.
In writing: Specify write data
In reading: Store read data
