Appendix
Rev.1.00 Jan. 10, 2008 Page 1647 of 1658
REJ09B0261-0100
Pin Name (LSI level)
Pin Name
(Module level)
Module I/O When Not in Use
TRDY PCIC
I/O
DISP DU O
TRDY/DISP
Port P2 GPIO I/O
Open* 2
CLKOUT CLKOUT CPG O Open
CLKOUTENB CLKOUTENB CPG O Open
PRESET PRESET
RESET I Must be used
NMI NMI INTC I Pulled-up to VDDQ
MRESETOUT RESET
O
MRESETOUT/
IRQOUT
IRQOUT INTC
O
Open
IRQ/
IRL[3:0] IRQ/IRL[3:0]
INTC I Pulled-up to VDDQ
MODE0 (power-on
reset) CPG I Must be used during power-on
reset
Port L4 (default) GPIO I/O
IRQ/
IRL4
INTC I
MODE0/
IRQ/
IRL4/
FD4
FD4 FLCTL I/O
Open
MODE1 (power-on
reset) CPG I Must be used during power-on
reset
Port L3 (default) GPIO I/O
IRQ/
IRL5 INTC
I
MODE1
IRQ/
IRL5/
FD5
FD5 FLCTL I/O
Open
MODE2 (power-on
reset) CPG I Must be used during power-on
reset
Port L2 (default) GPIO I/O
IRQ/
IRL6 INTC
I
MODE2/
IRQ/
IRL6/
FD6
FD6 FLCTL I/O
Open
MODE3 (power-on
reset) CPG I/O Must be used during power-on
reset
Port L1 (default) GPIO I/O Open
MODE3/
IRQ/
IRL7/
FD7
IRQ/
IRL7 INTC
I
FD7 FLCTL I/O
