19. Display Unit (DU)
Rev.1.00 Jan. 10, 2008 Page 826 of 1658
REJ09B0261-0100
Register Name Abbr. R/W
P4
Address Area 7
Address Size Synchronous
Clock
Plane 3 memory width register P3MWR R/W H'FFF80304 H'1FF80304 32 Pck
Plane 3 blend ratio register P3ALPHAR R/W H'FFF80308 H'1FF80308 32 Pck
Plane 3 display size X register P3DSXR R/W H'FFF80310 H'1FF80310 32 Pck
Plane 3 display size Y register P3DSYR R/W H'FFF80314 H'1FF80314 32 Pck
Plane 3 display position X
register P3DPXR R/W H'FFF80318 H'1FF80318 32 Pck
Plane 3 display position Y
register P3DPYR R/W H'FFF8031C H'1FF8031C 32 Pck
Plane 3 display area start
address 0 register P3DSA0R R/W H'FFF80320 H'1FF80320 32 Pck
Plane 3 display area start
address 1 register P3DSA1R R/W H'FFF80324 H'1FF80324 32 Pck
Plane 3 start position X register P3SPXR R/W H'FFF80330 H'1FF80330 32 Pck
Plane 3 start position Y register P3SPYR R/W H'FFF80334 H'1FF80334 32 Pck
Plane 3 wrap-around start
position register P3WASPR R/W H'FFF80338 H'1FF80338 32 Pck
Plane 3 wrap-around memory
width register P3WAMWR R/W H'FFF8033C H'1FF8033C 32 Pck
Plane 3 blinking period register P3BTR R/W H'FFF80340 H'1FF80340 32 Pck
Plane 3 transparent color 1
register P3TC1R R/W H'FFF80344 H'1FF80344 32 Pck
Plane 3 transparent color 2
register P3TC2R R/W H'FFF80348 H'1FF80348 32 Pck
Plane 3 memory length register P3MLR R/W H'FFF80350 H'1FF80350 32 Pck
Plane 4 mode register P4MR R/W H'FFF80400 H'1FF80400 32 Pck
Plane 4 memory width register P4MWR R/W H'FFF80404 H'1FF80404 32 Pck
Plane 4 blend ratio register P4ALPHAR R/W H'FFF80408 H'1FF80408 32 Pck
Plane 4 display size X register P4DSXR R/W H'FFF80410 H'1FF80410 32 Pck
Plane 4 display size Y register P4DSYR R/W H'FFF80414 H'1FF80414 32 Pck
Plane 4 display position X
register P4DPXR R/W H'FFF80418 H'1FF80418 32 Pck
Plane 4 display position Y
register P4DPYR R/W H'FFF8041C H'1FF8041C 32 Pck
