Appendix
Rev.1.00 Jan. 10, 2008 Page 1646 of 1658
REJ09B0261-0100
Pin Name (LSI level)
Pin Name
(Module level)
Module I/O When Not in Use
PCIFRAME PCIC
I/O
VSYNC DU
I/O
PCIFRAME/
VSYNC
Port P0 GPIO I/O
Open* 2
IDSEL IDSEL PCIC I Pulled-down to VSS
INTA PCIC
I/O
INTA
Port Q4 GPIO I/O
Open* 2 or pulled-up to VDDQ
when PCIC normal mode
IRDY PCIC
I/O
HSYNC
DU I/O
IRDY/HSYNC
Port P1 GPIO I/O
Open* 2
LOCK PCIC
I/O
ODDF DU I/O
LOCK/ODDF
Port P3 GPIO I/O
Open* 2
PAR PAR PCIC I/O Open* 2
PCICLK PCIC I PCICLK/
DCLKIN
DCLKIN DU I
When the bus mode selected
by MODE11 and MODE12
pins is a PCI host bus bridge
or a PCI normal (non-host)
mode, clock must be input to
the PCICLK pin.
When the bus mode selected
by MODE11 and MODE12
pins is a Local bus or Display
Unit mode, PCICLK pin must
be pulled-up to VDDQ or
pulled-down to GND.
PCIRESET PCIRESET PCIC
O Open
PERR PCIC
I/O
PERR
Port Q1 GPIO I/O
Open* 2
SERR PCIC
I/O
SERR
Port Q0 GPIO I/O
Open* 2
STOP/CDE STOP PCIC
I/O Open* 2
CDE DU O
Port P4 GPIO I/O
