10. Interrupt Controller (INTC)

Rev.1.00 Jan. 10, 2008 Page 308 of 1658
REJ09B0261-0100

Bit

Initial
Value R/W Source

Function

Description

SIOF

SIOF interrupt source
indication

PCIC (5)

PCIERR and PCIPWD3 to
PCIPWD0 interrupt source
indication

18 0

R PCIC (4)

PCIINTD interrupt source
indication

17 0

R PCIC (3)

PCIINTC interrupt source
indication

16 0

R PCIC (2)

PCIINTB interrupt source
indication

15 0

R PCIC (1)

PCIINTA interrupt source
indication

14 0

R PCIC (0)

PCISERR interrupt source
indication

13 0

R HAC channel

HAC channel 1 interrupt
source indication

12 0

R HAC channel

HAC channel 0 interrupt
source indication

11 0

R DMAC (1)

DMAC channels 6 to 11 and
address error interrupt
source indication

10 0

R DMAC (0)

DMAC channels 0 to 5 and
address error interrupt
source indication

9 0 R

H-UDI

H-UDI interrupt source
indication

These bits indicate the interrupt
source of each peripheral module
that is generating an interrupt.
(INT2A1 is affected by the setting
of the interrupt mask register).

0: No interrupt

1: An interrupt has occurred

Note: Interrupt sources can also

be identified by directly
reading the INTEVT code.
In this case, reading from
this register is not required.

8 0 R

WDT

WDT interrupt source
indication

7 0 R

SCIF
channel 5

SCIF channel 5 interrupt
source indication

6 0 R

SCIF
channel 4

SCIF channel 4 interrupt
source indication

5 0 R

SCIF
channel 3

SCIF channel 3 interrupt
source indication

4 0 R

SCIF
channel 2

SCIF channel 2 interrupt
source indication
