background image

31. Register List

Rev.1.00 Jan. 10, 2008 Page 1534 of 1658
REJ09B0261-0100

Module

Name Name

Abbrev.

Power-on

Reset by
PRESET Pin/
WDT/H-UDI

Manual Reset

by

WDT/Multiple

Exception

Sleep/

Deep Sleep by

SLEEP

Instruction

INTC

Interrupt control register 0

ICR0

H'x000 0000*

1

H'x000

0000*

1

Retained

Interrupt control register 1

ICR1

H'0000 0000

H'0000 0000

Retained

Interrupt priority register

INTPRI

H'0000 0000

H'0000 0000

Retained

Interrupt source register

INTREQ

H'0000 0000

H'0000 0000

Retained

Interrupt mask register 0

INTMSK0

H'0000 0000

H'0000 0000

Retained

Interrupt mask register 1

INTMSK1

H'FF00 0000

H'FF00 0000

Retained

Interrupt mask register 2

INTMSK2

H'0000 0000

H'0000 0000

Retained

Interrupt mask clear register 0

INTMSKCLR0 H'xx00 0000

H'xx00 0000

Retained

Interrupt mask clear register 1

INTMSKCLR1 H'x000 0000

H'x000 0000

Retained

Interrupt mask clear register 2

INTMSKCLR2 H'xxxx xxxx

H'xxxx xxxx

Retained

NMI flag control register

NMIFCR

H'x000 0000*

1

H'x000

0000*

1

Retained

User interrupt mask level register

USERIMASK

H'0000 0000

H'0000 0000

Retained

Interrupt priority register 0

INT2PRI0

H'0000 0000

H'0000 0000

Retained

Interrupt priority register 1

INT2PRI1

H'0000 0000

H'0000 0000

Retained

Interrupt priority register 2

INT2PRI2

H'0000 0000

H'0000 0000

Retained

Interrupt priority register 3

INT2PRI3

H'0000 0000

H'0000 0000

Retained

Interrupt priority register 4

INT2PRI4

H'0000 0000

H'0000 0000

Retained

Interrupt priority register 5

INT2PRI5

H'0000 0000

H'0000 0000

Retained

Interrupt priority register 6

INT2PRI6

H'0000 0000

H'0000 0000

Retained

Interrupt priority register 7

INT2PRI7

H'0000 0000

H'0000 0000

Retained

Interrupt priority register 8

INT2PRI8

H'0000 0000

H'0000 0000

Retained

Interrupt priority register 9

INT2PRI9

H'0000 0000

H'0000 0000

Retained

Interrupt source register

(not affected by the mask state)

INT2A0

H'xxxx xxxx

H'xxxx xxxx

Retained

Interrupt source register

(affected by the mask state)

INT2A1

H'0000 0000

H'0000 0000

Retained

Interrupt

mask

register

INT2MSKR

H'FFFF FFFF

H'FFFF FFFF

Retained

Interrupt mask clear register

INT2MSKCR

H'0000 0000

H'0000 0000

Retained

Module interrupt source register 0

INT2B0 H'xxxx

xxxx

H'xxxx xxxx

Retained

Module interrupt source register 1

INT2B1 H'xxxx

xxxx

H'xxxx xxxx

Retained
