31. Register List
Rev.1.00 Jan. 10, 2008 Page 1535 of 1658
REJ09B0261-0100
Module
Name Name Abbrev.
Power-on
Reset by
PRESET Pin/
WDT/H-UDI
Manual Reset
by
WDT/Multiple
Exception
Sleep/
Deep Sleep by
SLEEP
Instruction
INTC Module interrupt source register 2 INT2B2 H'xxxx xxxx H'xxxx xxxx Retained
Module interrupt source register 3 INT2B3 H'xxxx xxxx H'xxxx xxxx Retained
Module interrupt source register 4 INT2B4 H'xxxx xxxx H'xxxx xxxx Retained
Module interrupt source register 5 INT2B5 H'xxxx xxxx H'xxxx xxxx Retained
Module interrupt source register 6 INT2B6 H'xxxx xxxx H'xxxx xxxx Retained
Module interrupt source register 7 INT2B7 H'xxxx xxxx H'xxxx xxxx Retained
GPIO interrupt set register INT2GPIC H'0000 0000 H'0000 0000 Retained
LBSC Memory Address Map Select Register MMSELR H'0000 0000 H'0000 0000 Retained
Bus Control Register BCR H'x000 0000 Retained Retained
CS0 Bus Control Register CS0BCR H'7777 77F0 Retained Retained
CS1 Bus Control Register CS1BCR H'7777 77F0 Retained Retained
CS2 Bus Control Register CS2BCR H'7777 77F0 Retained Retained
CS3 Bus Control Register CS3BCR H'7777 77F0 Retained Retained
CS4 Bus Control Register CS4BCR H'7777 77F0 Retained Retained
CS5 Bus Control Register CS5BCR H'7777 77F0 Retained Retained
CS6 Bus Control Register CS6BCR H'7777 77F0 Retained Retained
CS0 Wait Control Register CS0WCR H'7777 770F Retained Retained
CS1 Wait Control Register CS1WCR H'7777 770F Retained Retained
CS2 Wait Control Register CS2WCR H'7777 770F Retained Retained
CS3 Wait Control Register CS3WCR H'7777 770F Retained Retained
CS4 Wait Control Register CS4WCR H'7777 770F Retained Retained
CS5 Wait Control Register CS5WCR H'7777 770F Retained Retained
CS6 Wait Control Register CS6WCR H'7777 770F Retained Retained
CS5 PCMCIA Control Register CS5PCR H'7700 0000 Retained Retained
CS6 PCMCIA Control Register CS6PCR H'7700 0000 Retained Retained
DDR2IF DBSC2 status register DBSTATE H'0000 0x00* 1 Retained Retained
SDRAM operation enable register DBEN H'0000 0000 Retained Retained
SDRAM command control register DBCMDCNT H'0000 0000 Retained Retained
SDRAM configuration setting register DBCONF H'009A 0001 Retained Retained
