26. Serial Sound Interface (SSI) Module
Rev.1.00 Jan. 10, 2008 Page 1301 of 1658
REJ09B0261-0100
26.3.1 Control Register (SSICR)
SSICR is a 32-bit readable/writable register that controls interrupts, selects each polarity status,
and sets operating mode.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
0 ⎯ ⎯ 0 0 0 ⎯ 0 0 0 0 0 0 0 0 0
BREN PDTA SDTA DEL SWSP SPDP SWSD SCKD SCKP MUEN CPEN TRMD EN
CHNL1 CHNL0 DWL2 IIEN OIEN DIEN DMEN UIEN DWL1
CKDV2 CKDV1 CKDV0
DWL0 SWL2 SWL1 SWL0
Bit:
Initial value:
R/W:
Bit:
Initial value:
R/W:
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R R R R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
⎯ ⎯ ⎯
Bit Bit Name
Initial
Value R/W Description
31 to 29
⎯ 0
R Reserved
These bits are always read as an undefined value. The
write value should always be 0.
28 DMEN 0 R/W DMA Enable
Enables or disables the DMA request.
0: DMA request disabled.
1: DMA request enabled.
27 UIEN 0 R/W Underflow Interrupt Enable
0: Underflow interrupt disabled
1: Underflow interrupt enabled
26 OIEN 0 R/W Overflow Interrupt Enable
0: Overflow interrupt disabled
1: Overflow interrupt enabled
25 IIEN 0 R/W Idle Mode Interrupt Enable
0: Idle mode interrupt disabled
1: Idle mode interrupt enabled
24 DIEN 0 R/W Data Interrupt Enable
0: Data interrupt disabled
1: Data interrupt enabled
