5. Exception Handling
Rev.1.00 Jan. 10, 2008 Page 89 of 1658
REJ09B0261-0100
Section 5 Exception Handling
5.1 Summary of Exception Handling
Exception handling processing is handled by a special routine which is executed by a reset,
general exception handling, or interrupt. For example, if the executing instruction ends
abnormally, appropriate action must be taken in order to return to the original program sequence,
or report the abnormality before terminating the processing. The process of generating an
exception handling request in response to abnormal termination, and passing control to a user-
written exception handling routine, in order to support such functions, is given the generic name of
exception handling.
The exception handling in this LSI is of three kinds: resets, general exceptions, and interrupts.
5.2 Register Descriptions
Table 5.1 lists the configuration of registers related exception handling.
Table 5.1 Register Configuration
Register Name Abbr. R/W P4 Address*
Area 7
Address* Access
Size
TRAPA exception register TRA R/W H'FF00 0020 H'1F00 0020 32
Exception event register EXPEVT R/W H'FF00 0024 H'1F00 0024 32
Interrupt event register INTEVT R/W H'FF00 0028 H'1F00 0028 32
Non-support detection exception
register EXPMASK R/W H'FF2F 0004 H'1F2F 0004 32
Note: * P4 is the address when virtual address space P4 area is used. Area 7 is the address
when physical address space area 7 is accessed by using the TLB.
