4. Pipelining
Rev.1.00 Jan. 10, 2008 Page 83 of 1658
REJ09B0261-0100
Functional
Category
No. Instruction
Instruction
Group
Issue Rate
Execution
Cycles Execution
Pattern
90 TST Rm,Rn EX 1 1 2-1
91 TST #imm,R0 EX 1 1 2-1
92 TST.B #imm,@(R0,GBR) CO 3 3 3-2
93 XOR Rm,Rn EX 1 1 2-1
94 XOR #imm,R0 EX 1 1 2-1
Logical
instructions
95 XOR.B #imm,@(R0,GBR) CO 3 3 3-2
96 ROTL Rn EX 1 1 2-1
97 ROTR Rn EX 1 1 2-1
98 ROTCL Rn EX 1 1 2-1
99 ROTCR Rn EX 1 1 2-1
100 SHAD Rm,Rn EX 1 1 2-1
101 SHAL Rn EX 1 1 2-1
102 SHAR Rn EX 1 1 2-1
103 SHLD Rm,Rn EX 1 1 2-1
104 SHLL Rn EX 1 1 2-1
105 SHLL2 Rn EX 1 1 2-1
106 SHLL8 Rn EX 1 1 2-1
107 SHLL16 Rn EX 1 1 2-1
108 SHLR Rn EX 1 1 2-1
109 SHLR2 Rn EX 1 1 2-1
110 SHLR8 Rn EX 1 1 2-1
Shift
instructions
111 SHLR16 Rn EX 1 1 2-1
112 BF disp BR 1+0 to 2 1 1-1
113 BF/S disp BR 1+0 to 2 1 1-1
114 BT disp BR 1+0 to 2 1 1-1
115 BT/S disp BR 1+0 to 2 1 1-1
116 BRA disp BR 1+0 to 2 1 1-1
117 BRAF Rm BR 1+3 1 1-2
Branch
instructions
118 BSR disp BR 1+0 to 2 1 1-1
119 BSRF Rm BR 1+3 1 1-2
