22. Serial I/O with FIFO (SIOF)
Rev.1.00 Jan. 10, 2008 Page 1110 of 1658
REJ09B0261-0100
22.3.5 Transmit Control Data Register (SITCR)
SITCR is a 32-bit readable/writable register that specifies transmit control data of the SIOF. The
setting of SITCR is valid only when bits FL3 to FL0 in SIMDR are set to 1xxx (x: any value).
SITCR is initialized by the conditions shown in table 22.3, Register State in Each Operating
Mode, or by a transmit reset by the TXRST bit in SICTR.
16 17 18 19 20 21 22 23 24 25 26 27 28 29 31 30
— — — — — — — — — — — — — — — —
SITC0[15:0]
R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
BIt:
Initial value:
R/W:
0 1 2 3 4 5 6 7 8 9 10 11 12 13 15 14
— — — — — — — — — — — — — — — —
SITC1[15:0]
BIt:
Initial value:
R/W:
Bit Bit Name
Initial
Value R/W Description
31 to 16 SITC0[15:0] H'0000 R/W Control Channel 0 Transmit Data
These bits specify data to be output from the
SIOF_TXD pin as control channel 0 transmit data. The
position of the control channel 0 data in the transmit or
receive frame depends on the value set in the CD0A bit
in SICDAR.
• These bits are valid when the CD0E bit in SICDAR
is set to 1.
15 to 0 SITC1[15:0] H'0000 R/W Control Channel 1 Transmit Data
These bits specify data to be output from the
SIOF_TXD pin as control channel 1 transmit data. The
position of the control channel 1 data in the transmit or
receive frame depends on the CD1A bit in SICDAR.
• These bits are valid when the CD1E bit in SICDAR
is set to 1.
