28. General Purpose I/O Ports (GPIO)
Rev.1.00 Jan. 10, 2008 Page 1420 of 1658
REJ09B0261-0100
28.2.19 Port C Data Register (PCDR)
PCDR is an 8-bit readable/writable register that stores port C data.
0 1 2 3 4 5 6 7
0 0 0 0 0 0 0 0
PC0DT PC1DT PC2DT PC3DT PC4DT PC5DT PC6DT PC7DT
R/W R/W R/W R/W R/W R/W R/W R/W
Bit:
Initial value:
R/W:
Bit Bit Name
Initial
value R/W Description
7 PC7DT 0 R/W
6 PC6DT 0 R/W
5 PC5DT 0 R/W
4 PC4DT 0 R/W
3 PC3DT 0 R/W
2 PC2DT 0 R/W
These bits store output data of a pin which is used as a
general-purpose output port. When the pin functions as
a general-purpose output port, reading the port will read
out the value of the corresponding bit of this register.
When the pin functions as a general-purpose input port,
reading the port will read out the status of the
corresponding pin.
1 PC1DT 0 R/W
0 PC0DT 0 R/W
