30. User Debugging Interface (H-UDI)
Rev.1.00 Jan. 10, 2008 Page 1495 of 1658
REJ09B0261-0100
Number Pin Name Type Number Pin Name Type
499 NMI Input 467
REQ0/REQOUT Control
498 NMI Control 466
REQ0/REQOUT Output
497 NMI Output 465
PERR Input
496
INTA Input
464
PERR Control
495
INTA Control
463
PERR Output
494
INTA Output
462
SERR Input
493 CLK/DCLKIN Input 461
SERR Control
492
PCIRESET Input
460
SERR Output
491
PCIRESET Control
459
STOP/CDE Input
490
PCIRESET Output
458
STOP/CDE Control
489
GNT3/MMCCLK Input
457
STOP/CDE Output
488
GNT3/MMCCLK Control
456 PAR Input
487
GNT3/MMCCLK Output
455 PAR Control
486
GNT2 Input
454 PAR Output
485
GNT2 Control
453
DEVSEL/DCLKOUT Input
484
GNT2 Output
452
DEVSEL/DCLKOUT Control
483
GNT1 Input
451
DEVSEL/DCLKOUT Output
482
GNT1 Control
450
LOCK/ODDF Input
481
GNT1 Output
449
LOCK/ODDF Control
480
REQ3/MMCCD Input
448
LOCK/ODDF Output
479
REQ3/MMCCD Control
447 IDSEL Input
478
REQ3/MMCCD Output
446 IDSEL Control
477
REQ2 Input
445 IDSEL Output
476
REQ2 Control
444
TRDY/DISP Input
475
REQ2 Output
443
TRDY/DISP Control
474
REQ1 Input
442
TRDY/DISP Output
473
REQ1 Control
441
IRDY/HSYNC Input
472
REQ1 Output
440
IRDY/HSYNC Control
471
GNT0/GNTIN Input
439
IRDY/HSYNC Output
470
GNT0/GNTIN Control
438
FRAME/VSYNC Input
469
GNT0/GNTIN Output
437
FRAME/VSYNC Control
468
REQ0/REQOUT Input
436
FRAME/VSYNC Output
