27. NAND Flash Memory Controller (FLCTL)
Rev.1.00 Jan. 10, 2008 Page 1356 of 1658
REJ09B0261-0100
Bit Bit Name
Initial
Value R/W Description
18 AC0CLR 0 R/W FLDTFIFO Clear
Clears the address counter of FLDTFIFO.
0: Retains the address counter value of FLDTFIFO. In
flash-memory access, clear this bit to 0.
1: Clears the address counter of FLDTFIFO. After
clearing the counter, clear this bit to 0
17 DREQ1EN 0 R/W FLECFIFODMA Request Enable
Enables or disables the DMA transfer request issued
from FLECFIFO.
0: Disables the issue of DMA transfer request from
FLECFIFO
1: Enables the issue of DMA transfer request from
FLECFIFO
16 DREQ0EN 0 R/W FLDTFIFODMA Request Enable
Enables or disables the DMA transfer request issued
from FLDTFIFO.
0: Disables the issue of DMA transfer request from
FLDTFIFO
1: Enables the issue of DMA transfer request from
FLDTFIFO
15 to 9 — All 0 R Reserved
These bits are always read as 0. The write value should
always be 0.
8 STERB 0 R/W Status Error
Indicates the result of status read. This bit is set to 1 if
the specific bit in bits STAT7 to STAT0 in FLBSYCNT is
set to 1 in status read.
Since this bit is a flag bit, 1 cannot be written to this bit.
Only 0 can be written to clear the flag.
0: Indicates that no status error occurs (the specific bit
in bits STAT7 to STAT0 in FLBSYCNT is 0.)
1: Indicates that a status error occurs
For details on the specific bit, see section 27.4.4, Status
Read.
