31. Register List
Rev.1.00 Jan. 10, 2008 Page 1520 of 1658
REJ09B0261-0100
Module
Name Name Abbreviation R/W
P4 Area
Address
Area 7
Address
Access
Size
DU Base color register BPOR R/W H'FFF80098 H'1FF80098 32
Raster interrupt offset register RINTOFSR R/W H'FFF8009C H'1FF8009C 32
Plane 1 mode register P1MR R/W H'FFF80100 H'1FF80100 32
Plane 1 memory width register P1MWR R/W H'FFF80104 H'1FF80104 32
Plane 1 blend ratio register P1ALPHAR R/W H'FFF80108 H'1FF80108 32
Plane 1 display size X register P1DSXR R/W H'FFF80110 H'1FF80110 32
Plane 1 display size Y register P1DSYR R/W H'FFF80114 H'1FF80114 32
Plane 1 display position X register P1DPXR R/W H'FFF80118 H'1FF80118 32
Plane 1 display position Y register P1DPYR R/W H'FFF8011C H'1FF8011C 32
Plane 1 display area start address 0 register P1DSA0R R/W H'FFF80120 H'1FF80120 32
Plane 1 display area start address 1 register P1DSA1R R/W H'FFF80124 H'1FF80124 32
Plane 1 start position X register P1SPXR R/W H'FFF80130 H'1FF80130 32
Plane 1 start position Y register P1SPYR R/W H'FFF80134 H'1FF80134 32
Plane 1 wrap-around start position register P1WASPR R/W H'FFF80138 H'1FF80138 32
Plane 1 wrap-around memory width register P1WAMWR R/W H'FFF8013C H'1FF8013C 32
Plane 1 blinking period register P1BTR R/W H'FFF80140 H'1FF80140 32
Plane 1 transparent color 1 register P1TC1R R/W H'FFF80144 H'1FF80144 32
Plane 1 transparent color 2 register P1TC2R R/W H'FFF80148 H'1FF80148 32
Plane 1 memory length register P1MLR R/W H'FFF80150 H'1FF80150 32
Plane 2 mode register P2MR R/W H'FFF80200 H'1FF80200 32
Plane 2 memory width register P2MWR R/W H'FFF80204 H'1FF80204 32
Plane 2 blend ratio register P2ALPHAR R/W H'FFF80208 H'1FF80208 32
Plane 2 display size X register P2DSXR R/W H'FFF80210 H'1FF80210 32
Plane 2 display size Y register P2DSYR R/W H'FFF80214 H'1FF80214 32
Plane 2 display position X register P2DPXR R/W H'FFF80218 H'1FF80218 32
Plane 2 display position Y register P2DPYR R/W H'FFF8021C H'1FF8021C 32
Plane 2 display area start address 0 register P2DSA0R R/W H'FFF80220 H'1FF80220 32
Plane 2 display area start address 1 register P2DSA1R R/W H'FFF80224 H'1FF80224 32
Plane 2 start position X register P2SPXR R/W H'FFF80230 H'1FF80230 32
Plane 2 start position Y register P2SPYR R/W H'FFF80234 H'1FF80234 32
Plane 2 wrap-around start position register P2WASPR R/W H'FFF80238 H'1FF80238 32
