19. Display Unit (DU)
Rev.1.00 Jan. 10, 2008 Page 860 of 1658
REJ09B0261-0100
Bit Bit Name
Initial
Value R/W Internal
Update Description
19 DPE5 0 R/W Yes Display Plane Priority 5 Enable
18 to 16 DPS5 100 R/W Yes Display Plane Priority 5 Select
1000: Selects and displays plane 1 in priority 5
1001: Selects and displays plane 2 in priority 5
1010: Selects and displays plane 3 in priority 5
1011: Selects and displays plane 4 in priority 5
1100: Selects and displays plane 5 in priority 5
1101: Selects and displays plane 6 in priority 5
1110: Setting prohibited
1111: Setting prohibited
0---: Priority 5 is not displayed
15 DPE4 0 R/W Yes Display Plane Priority 4 Enable
14 to 12 DPS4 011 R/W Yes Display Plane Priority 4 Select
1000: Selects and displays plane 1 in priority 4
1001: Selects and displays plane 2 in priority 4
1010: Selects and displays plane 3 in priority 4
1011: Selects and displays plane 4 in priority 4
1100: Selects and displays plane 5 in priority 4
1101: Selects and displays plane 6 in priority 4
1110: Setting prohibited
1111: Setting prohibited
0---: Priority 4 is not displayed
