27. NAND Flash Memory Controller (FLCTL)

Rev.1.00 Jan. 10, 2008 Page 1359 of 1658

REJ09B0261-0100

27.3.9

Ready Busy Timeout Setting Register (FLBSYTMR)

FLBSYTMR is a 32-bit readable/writable register that specifies the timeout time when the FRB
pin is busy.

31

30

29

28

27

26

25

24

23

22

21

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

R

R

R

R

R

R

R

R

R

R

R

R/W

R/W

R/W

R/W

R/W

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

Bit:

Initial value:

R/W:

Bit:

Initial value:

R/W:

RBTMOUT[20:16]

RBTMOUT[15:0]

Bit Bit

Name

Initial
Value R/W Description

31 to 21 —

All 0

R

Reserved

These bits are always read as 0. The write value
should always be 0.

20 to 0

RBTMOUT[20:0] H'00000 R/W

Ready Busy Timeout

Specify timeout time in the busy state

Set the timeout time in the busy state (with the clock
cycles of a peripheral clock)

When these bits are set to 0, timeout does not
occur.
