10. Interrupt Controller (INTC)
Rev.1.00 Jan. 10, 2008 Page 268 of 1658
REJ09B0261-0100
Source
Number of
Sources
(Max.) Priority
INTEVT
Remarks
H'320
IRL[3:0] pin = HLLH (H'9)
H'C20
IRL[7:4] pin = HLLH (H'9)
H'340
IRL[3:0] pin = HLHL (H'A)
External
interrupts
IRL 2
H'C40
IRL[7:4] pin = HLHL (H'A)
High
H'360
IRL[3:0] pin = HLHH (H'B)
H'C60
IRL[7:4] pin = HLHH (H'B)
H'380
IRL[3:0] pin = HHLL (H'C)
H'C80
IRL[7:4] pin = HHLL (H'C)
H'3A0
IRL[3:0] pin = HHLH (H'D)
H'CA0
IRL[7:4] pin = HHLH (H'D)
H'3C0
IRL[3:0] pin = HHHL (H'E)
Inverse of values on
the input pins
(because the signals
are active low)
Input level
H: high level
L: low level
(see table 10.11)
H'CC0
IRL[7:4] pin = HHHL (H'E) Low
8
Values set in INTPRI
H'240
IRQ[0]
High
IRQ
interrupt
H'280
IRQ[1]
H'2C0
IRQ[2]
H'300
IRQ[3]
H'340
IRQ[4]
H'380
IRQ[5]
H'3C0
IRQ[6]
H'200
IRQ[7]
Low
WDT 1
H'560 ITI*
TMU-ch0 1
Values set in
INT2PRI0 to INT2PRI9
H'580 TUNI0*
TMU-ch1 1
H'5A0
TUNI1*
TMU-ch2 2
H'5C0
TUNI2*
On-chip
peripheral
module
interrupts*
H'5E0
TICPI2*
H-UDI
1
H'600
H-UDII
DMAC(0)
7
H'620
DMINT0*
H'640
DMINT1*
H'660
DMINT2*
