For more information about IP ACLs, see Configure a basic or extended IPv4 ACL
on page 804.
•
MAC ACL: Traffic is filtered according to the MAC ACL for which you must type
the name in the Filter Name field. Only traffic that matches the rules in the MAC
ACL is mirrored to the destination port.
For more information about MAC ACLs, see Configure a MAC ACL on page 794.
The following steps refer to the Source Interface Configuration section, in which you
must select one or more source interfaces and set the traffic direction.
10. Select whether to display physical interfaces, LAGs, the CPU, VLANs, or all by clicking
one of the following links above the table heading:
•
1 or Unit ID for a stacked switch:
-
1: If no switch stack is configured, the physical interfaces for the switch are
displayed.
-
Unit ID for a stacked switch: If a switch stack is configured, the physical
interfaces for the switch with the selected stack unit ID are displayed.
•
LAG: Only LAGs are displayed.
•
CPU: Only the CPU is displayed.
•
VLANS: Only VLANs are displayed.
•
All: Physical interfaces, LAGs, the CPU, and VLANs are displayed, or for a switch
stack, physical interfaces on all switches in the stack, LAGs, the CPU, and VLANs
are displayed.
11. Use one of the following methods to select an interface:
•
In the Go To Interface field, enter the interface in the unit/slot/port format and
click on the Go button.
•
Next to the Interface column, select the check box for the interface or interfaces
that you want to include.
NOTE:
If an interface is a member of a VLAN
and
is member of a LAG,
you cannot select the VLAN as a source VLAN. However, if an interface is a
member of a VLAN that you select as a source VLAN, the interface
can
be
a member of a LAG.
12. From the Direction menu, select the direction of the traffic that must be mirrored
from the configured source ports.
•
None: The port (or VLAN) is not mirrored.
•
Tx and Rx: Both egress (transmitted) and egress (received) traffic is mirrored.
For a VLAN, this option select the VLAN as the source VLAN.
