Table 95. MVRP statistics information

Description

Field

MVRP Global Statistics

The number of MMRP frames that were received on the switch.

Frames Received

The number of MMRP frames with bad headers that were received on the
switch.

Bad Header

The number of MMRP frames with bad PDUs body formats that were received
on the switch.

Bad Format

The number of MMRP frames that were transmitted on the switch.

Frames Transmitted

The number of MMRP frames that the switch did not transmit.

Transmission Failures

The number of MMRP messages that were not added to the queue.

Message Queue Failures

MVRP Statistics

The interface for which information is displayed.

Interface

The number of MVRP frames that were received on the interface.

Frames Received

The number of MVRP frames with bad headers that were received on the
interface.

Bad Header

The number of MVRP frames with bad PDUs body formats that were received
on the interface.

Bad Format

The number of MVRP frames that were transmitted on the interface.

Frames Transmitted

The number of MVRP frames that the interface failed to transmit.

Transmission Failures

The number of MVRP frames that failed to register on a device or particular
interface.

Registration Failures

Display or clear MSRP statistics

You can display or clear information about the MSRP frames transmitted and received
by the switch and by each interface.

To display or clear MSRP statistics:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

If you do not know the IP address of the switch, see Log in to the main UI with a web
browser
on page 27 and the subsections.

The login page displays.

3. Click the Main UI Login button.
