To change the hash mode for the Auto-LAGs:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Log in to the main UI with a web
browser on page 27 and the subsections.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Switching > LAG > LAG Configuration.
The LAG Configuration page displays.
6. In the LAG Global Configuration section, from the Auto-LAG Global Hash Mode
menu, select the hash mode for the Auto-LAGs:
• 1 Src MAC, VLAN, EType, incoming port: Source MAC address, VLAN,
EtherType, and incoming port associated with the packet.
• 2 Dest MAC, VLAN, EType, incoming port: Destination MAC address, VLAN,
EtherType, and incoming port associated with the packet. This is the default
mode.
• 3 Src/Dest MAC, VLAN, EType, incoming port: Source and destination MAC
addresses, VLAN, EtherType, and incoming port associated with the packet.
• 4 Src IP and Src TCP/UDP Port fields: Source IP address and source TCP/UDP
port fields of the packet.
• 5 Dest IP and Dest TCP/UDP Port fields: Destination IP address and destination
TCP/UDP port fields of the packet.
• 6 Src/Dest IP and TCP/UDP Port fields: Source and destination IP addresses
and source and destination TCP/UDP port fields of the packet.
• 7 Enhanced hashing mode: Features MODULO-N operation based on the
number of ports in the LAG, non-unicast traffic and unicast traffic hashing using
a common hash algorithm, excellent load balancing performance, and packet
attributes selection based on the packet type
