Table 179. Interface Binding Status information (Continued)
Description Field
The ACL number or name identifying the ACL assigned to the selected interface and
direction. ACL ID/Name
The sequence number signifying the order of specified ACL relative to other ACLs
assigned to the selected interface and direction. Sequence Number
Display or delete IP ACL bindings in the IP
ACL binding table
You can display or delete bindings for basic IPv4, extended IPv4, and IPv6 ACLs.
To display or delete IP ACL bindings:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Log in to the main UI with a web
browser on page 27 and the subsections.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Security > ACL > Advanced > Binding Table.
The IP ACL Binding Table page displays. The table displays the IP ACL-to-interface
bindings.
6. To delete an IP ACL-to-interface binding, do the following:
a. Select the check box next to the interface.
b. Click the Delete button.
The binding is removed.
7. To save the settings to the running configuration, click the Save icon.
The following table describes the view-only fields on the page.
