NETGEAR M4350-24F4V 24-Port 10G SFP+ Managed AV Network Switch User Manual
Page 447
•
Active: The primary virtual router is enabled.
•
Inactive: The primary virtual router is configured but disabled.
13. Click the Add button.
Your settings are saved. The primary virtual router is added.
14. To save the settings to the running configuration, click the Save icon.
The following table describes the view-only fields on the page.
Description
Field
The IP address that is associated with the interface. This IP address can be different
from the primary IP address.
Interface IP Address
The state of the virtual router:
• Initializing: The virtual router is in the process of initializing.
• Primary: The virtual router completed initialization and functions as the primary
router.
• Secondary: The virtual router completed initialization and functions as the secondary
router.
State
Enable VRRP and add a primary virtual
router with enhanced settings
You can enable VRRP and add a primary virtual router by configuring its virtual router
ID (VRID), selecting its interface, and settings its primary IP address. In addition, you can
configure multiple enhanced settings.
To enable VRRP and add a primary virtual router with enhanced settings
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Log in to the main UI with a web
browser on page 27 and the subsections.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
Main User Manual
447
Manage Routing
Fully Managed Switches M4350 Series Main User Manual
