Table 73. MFDB information

Description

Field

The multicast MAC address for which you requested data.

MAC Address

The VLAN ID to which the multicast MAC address is related.

VLAN ID

The component that is responsible for this entry in the MFDB. The
component can be IGMP snooping, GMRP, Static Filtering, or MLD
snooping.

Component

The type of the entry. Static entries are those that you configure. Dynamic
entries are added to the table as a result of a learning process or protocol.

Type

The description of this multicast table entry. The description can be
Management Configured, Network Configured, or Network Assisted.

Description

The forwarding list that is derived from combining all the forwarding
interfaces and removing the interfaces that are listed as the static filtering
interfaces.

Forwarding Interfaces

Remove the IGMP snooping entries from
the multicast forwarding database

You can remove the IGMP snooping entries from the multicast forwarding database.

To remove the IGMP snooping entries from the multicast forwarding database:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

If you do not know the IP address of the switch, see Log in to the main UI with a web
browser
on page 27 and the subsections.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.

The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Switching > Multicast > MFDB > MFDB Table.

The MFDB Table page displays.

6. Click the Clear button.
